M14 Series

PN: M16020301M02-xx

Name: M16 series 2pin male plug(Push lock type, Overmolded 180°)

Features:

-Push lock mating type makes the mating operation on site highly convenient.

-IP67 waterproof protection.

-2,3,4,5,6,7,8,10,12,14pin models cover different application

-Multiple Fool-proof designs avoid wrong connection on device

-Orange, blue and black color clamping ring and screw nut for option.

-Max. working current and voltage rate 10A, 300V.

-Extraordinary electrical features such as 1500V withstand voltage support.

-High performance PA66 Nylon material resist the harsh environment.
